Film width: Max.620mm
Film width range(bag former): 300-620mm
Bag width: 140-300mm
Bag length: 80-450mm
Film roll diameter: Max.400mm
Packing rate: 10-30bag/min
Measurement range: 150-3000ml
Film thickness: 0.07-0.15mm
Power: 220V,50HZ, single phase
Machine size: (L)4400*(W)1800*(H)4200mm
Machine weight: 1800kg
1. New design, beautiful appearance, reasonable structure, more advanced technology;
2. Imported PLC computer control system, color touch screen easy, intuitive and efficient;
3. Import servo film transporting system, import color sensor, accurate positioning machine performance packaging beautifully;
4. Multiple automatic alarm protons educating the maximum loss;
5. Bag-shaped variety, can provide customers with pillow-shaped bags, thrust Angle bags, hang hole bags, even bags;
6. Suitable for packing all kinds of chips, rice, nuts, dry fruits, puffed food, candy, peanut, melon seeds, seeds, popcorn, salt, sugar and other powdered, granular, strip product etc packing.
Free consultation service before, during and after sales;
Free project planning and design services;
Free debugging of equipment until everything is functional;
Free training of equipment maintenance and operation personally;
Free new production techniques and formulas;
Machine provides 1 year complete warranty and full lifetime maintenance service.
| Model: | HF-620 |
| Film width | Max.620mm |
| Film width Range(bag former) | 300-620mm |
| Front Width | 60-200mm |
| Side Width | 50-90 mm |
| Width is side seal | 5-10 mm |
| Bag Length | 80-450mm |
| Film roll Diameter: | Max.400mm |
| Packing rate: | 10-30bag/min |
| Measurment range: | 150-3000ml |
| Film thickness: | 0.07-0.15mm |
| Power: | 220V,50HZ, single phase |
| Machine size: | (L)4400*(W)1800*(H)4200mm |
| Machine Weight: | 1800kg |
| Remark | Pneumatic Type |
