Packing speed：30~120 bags/min
Film size：90-400mm
Package length：120-500mm
Package width：35-140mm
General power：2.8KW
It is suitable for packing irregular objects and solid objects. For hardware, electrical appliances, switches, small commodities, daily chemical, chemical and other industries.
The machine is controlled by three servos.
Conveyor under the belt, can pass heavier (30g) materials; The brush can make the envelope more flat and meet the exhaust demand. The tool holder can pass through the larger size of the material.
Seven-inch touch screen display, easy operation, clear working state.
Can store a variety of product parameters and formulations, do not need to repeat Settings, download and use.
Automatically adjust the bag length without manual setting.
Higher precision, accurate sealing and cutting position.
Stop position and print position can be set arbitrarily.
Simple mechanical structure, convenient and intuitive debugging, low after-sales maintenance cost.
The range of packaging is expanded to accommodate a variety of product specifications.
The structure layout in line with human engineering mechanics can facilitate the hygienic cleaning, maintenance, maintenance and overhaul of the machine quickly.
Reduce the labor intensity of the operator and effectively improve the production efficiency.
|
Model |
MC-1000Plus |
|
Packing speed |
30-120 bag/min |
|
Film size |
90-400 mm |
|
Package length |
120-500mm |
|
Package width |
35-140 mm |
|
Package height |
5-60 mm |
|
General power |
2.8Kw |
|
Packaging film type |
PP、CPP、PVC、PS、EVA、PET、PVDC/PVC、OPP/CPP ETC. |
|
Power supply |
220v/50Hz |
|
Machine size |
3590 x 960 x1080 mm |
|
Net weight |
340 kg |
